The SilentiumPC CCTV system power supply converts an input voltage of 230 V AC to a regulated 12 V DC output. The switching power supply is mounted on a T-35 DIN rail and provides 120 W of power with a maximum current of 10 A.
- Type: Switching
- Input voltage: 88–264 V AC
- Rated AC supply voltage at 50 Hz: 230 V
- Maximum AC supply voltage at 50 Hz: 264 V
- Output voltage: 12–14 V DC
- Output power: 120 W
- Maximum current: 10 A
- Peak load: Up to 150% of rated power for 3 seconds
- Mounting: On a T-35 DIN rail
- Connection: Screw terminal
- Protections: Thermal, short-circuit, overload and overvoltage
- Protection rating: IP20
- Dimensions: 40 × 113.5 × 125.2 mm (width × depth × height)
- Weight: 0.67 kg
- Type
- Power Supply
