FF Professional Analog Single Phase Electric Panel Meter

The FF Professional analog single-phase panel meter uses a closed-core current transformer with a transformation ratio of 200/5 A. It converts a primary current of up to 200 A into a secondary current...

The FF Professional analog single-phase panel meter uses a closed-core current transformer with a transformation ratio of 200/5 A. It converts a primary current of up to 200 A into a secondary current of 5 A for measurement in electrical and industrial installations.

  • Display type: Analog
  • Number of phases: Single-phase
  • Maximum current: 200 A
  • Rated secondary...
See full description See full description

Top specs

See all
77 65 €
Delivery Tue, 01 Dec - Thu, 03 Dec
3,50 € to a Skroutz Point or 4,50 € to an address
Do you want it with Free shipping?
Sent from Greece
From Getters 4.5 (118)
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund. Learn more

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Learn more about invoicing
Questions

Description & Specifications

The FF Professional analog single-phase panel meter uses a closed-core current transformer with a transformation ratio of 200/5 A. It converts a primary current of up to 200 A into a secondary current of 5 A for measurement in electrical and industrial installations.

  • Display type: Analog
  • Number of phases: Single-phase
  • Maximum current: 200 A
  • Rated secondary current: 5 A
  • Power: 2.5 VA
  • Frequency: 50–60 Hz
  • Accuracy class: 0.2S
  • Maximum operating voltage: 0.66 kV AC
  • Operating voltage: 0.66/0.72 kV
  • Insulation withstand voltage: 3 kV/1 min
  • Safety factor: FS
  • Insulation class: E
  • Continuous thermal current: 1.2 × In
  • Short-time thermal current: 60 × In
  • Dynamic current: 2.5 × Ith
  • Terminal connection: Screw, S1/S2, 4 mm²
  • Aperture: 32 × 32 mm
  • Dimensions: 75 × 98 × 42 mm
  • Tightening torque: 0.5 Nm
  • Operating temperature: -5–40 °C
  • Mounting: Vertical or horizontal
  • Protection rating: IP20
  • Standards: PN-EN 61869-12009, PN-EN 61869-22013-06
  • Weight: 0.5 kg

Manufacturer

Display Type
Analog
Number of Phases
Single-phase
Maximum Current
200 A

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
