The SilentiumPC KDR 12048 LED power supply mounts on a T-35 DIN rail and provides a regulated 48 V DC output, with a power rating of 120 W and a maximum current of 2.5 A. It features a DC-OK LED indicator and screw terminals, while its protections cover thermal overload, short circuit, and overvoltage.
- Type: DIN rail
- Protection rating: IP20
- Output voltage: 48 V DC
- Output voltage adjustment: 48–55 V
- Power: 120 W
- Maximum current: 2.5 A
- AC supply voltage range: 88–264 V
- DC supply voltage range: 120–370 V
- Indicator: DC-OK LED
- Connection: Screw terminals
- Protections: Thermal, short-circuit, overload, and overvoltage
- Short-circuit protection: Yes
- Cooling: Natural airflow
- Efficiency: 90.5%
- Operating temperature: -30 to +70 °C
- Version: Modular
- Type
- Rail
- Output (DC)
- 48 V
- Power
- 120 W
- Waterproofing
- IP20
