The FNIRSI TSG3020 signal generator combines high signal generation accuracy with intuitive operation, making it suitable for use in laboratories and workshops. Its dual-channel design, the output frequency up to 60 MHz, the 200 MSa/s sampling rate, and the 14-bit resolution enable the creation of high-quality signals with minimal distortion.
The device offers a wide selection of standard and arbitrary waveforms, supports six types of modulation, and frequency sweep operation. The built-in frequency counter further enhances its measurement capabilities. It features a clear touchscreen display and advanced signal quality enhancement technologies.
Key features:
- Two independent output channels.
- Maximum output frequency: 60 MHz.
- Amplitude range from 2 mVpp to 20 Vpp at frequencies below 10 MHz.
- Supports standard and arbitrary waveforms such as sine, square, ramp, pulse, noise, and DC.
- Six types of modulation: AM, FM, PM, FSK, ASK, and PSK.
- Sweep functions: linear and logarithmic.
- Built-in 7-digit frequency counter.
- Display: 4.3” TFT LCD, 480 x 272.
The device features comprehensive output protection functions and an efficient cooling system, ensuring safe and stable operation. The non-volatile memory allows storage of up to 24 custom arbitrary waveforms.
The set includes: function generator, power adapter, Type-C charging cable, data cable, measurement cable, alligator clip, user manual.
