- Input voltage range
- 162 VAC to 268 VAC (220V)
- 170 VAC to 280 VAC (230V)
- 177 VAC to 290 VAC (240V)
- Socket type Schuko
- Output voltage range 220/230VAC ± 10%
- Output frequency 50/60 Hz ± 0.5 Hz auto-adaptive
- Transfer time ≤ 10 ms
- Simulated sine wave waveform
- Socket type Schuko
- Battery type 12 V/9 Ah x 2, lead-acid battery
- Recharge time 6-8 hours to restore to 90% of capacity
- Typical backup time Runtime at 300w: 15-20 minutes
- Communication ports USB
- Full protection against surge, overload protection, discharge protection, short-circuit protection
- LCD display
- AC mode, Battery mode, Load level, Battery level, Input voltage, Output voltage,
- Overload, Fault and Low Battery
- Battery mode: Beeps every 10 seconds.
- Low battery: Beeps every second.
- Overload: Beeps every 0.5 seconds.
- Fault: Continuous alarm.
- Operating temperature 0 °C to 40 °C (32 °F to 104 °F)
- Operating humidity 0% to 90% (non-condensing)
- Dimensions 124 mm × 382.42 mm × 225.1 mm (4.88" × 15.06" × 8.86")
- Weight Approximately 10.5 kg (23.15 lb)
- Input voltage range
- 162 VAC to 268 VAC (220V)
- 170 VAC to 280 VAC (230V)
- 177 VAC to 290 VAC (240V)
- Socket type Schuko
- Output voltage range 220/230VAC ± 10%
- Output frequency 50/60 Hz ± 0.5 Hz auto-adaptive
- Transfer time ≤ 10 ms
- Simulated sine wave waveform
- Socket type Schuko
- Battery type 12 V/9 Ah x 2, lead-acid battery
- Recharge time 6-8 hours to restore to 90% of capacity
- Typical backup time Runtime at 300w: 15-20 minutes
- Communication ports USB
- Full protection against surge, overload protection, discharge protection, short-circuit protection
- LCD display
- AC mode, Battery mode, Load level, Battery level, Input voltage, Output voltage,
- Overload, Fault and Low Battery
- Battery mode: Beeps every 10 seconds.
- Low battery: Beeps every second.
- Overload: Beeps every 0.5 seconds.
- Fault: Continuous alarm.
- Operating temperature 0 °C to 40 °C (32 °F to 104 °F)
- Operating humidity 0% to 90% (non-condensing)
- Dimensions 124 mm × 382.42 mm × 225.1 mm (4.88" × 15.06" × 8.86")
- Weight Approximately 10.5 kg (23.15 lb)
Dimensions
- Type
- (VI) Line-Interactive
- Power (VA)
- 2000 VA
- Power (Watt)
- 1200 W
- Size
- Tower
- Noise Level
- -
- Display Screen
- Digital Display
Connectivity
- USB
- Yes
- Plug Type
- Schuko
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
