The HikVision HiLook NS-0526P-225 switch is a powerful solution for large networks, offering 24 PoE Gigabit ports (10/100/1000 Mbps) and 2 Gigabit SFP uplink ports, making it ideal for video surveillance systems, corporate networks, and commercial applications. It is unmanaged, allowing plug & play operation without additional configurations.
- Compatibility: IEEE 802.3af and IEEE 802.3at
- PoE Budget: 225W, maximum power 30W per port
- Switching Capacity: 52 Gbps
- Forwarding Rate: 38.69 Mpps
- MAC Address Table: 8K
- Internal Cache: 4.1 Mbits
- Material: Metal
- Protection: Surge protection up to 6 kV
- Operating Temperature: 0°C - 45°C
- Power Supply: 100-240 VAC, 50/60 Hz, maximum consumption 2.5A
- Dimensions: 440 x 44 x 220.8 mm
- Weight: 2.92 kg
Network Specifications
- Type
- Unmanaged
- Layer
- L2
- PoE
- Yes
- PoE Version
- 802.3af, 802.3at
Technical Specifications
- Ethernet connections
- 24 Port
- Ethernet Speed
- 1000 Mbps
- Switching Speed
- 52 Gbps
- MAC Address Table
- 8000 entries
- Rack mounting
- Yes
