Perfexim PHA-004 Ball Valves (THREAD WZ) DN25 1 - red butterfly

Product features: The Perfekt System ball valves are an ideal choice for any hydraulic installation. This is a private label brand created under the supervision of experts in the field of hydraulic and thermal installations. Hydraulic connections must have a robust construction that ensures effective and smooth water flow. High-quality valves feature self-locking nuts that secure the water connections against spontaneous loosening and disassembly. They are durable and have been designed with attention to detail, offering safety and high-quality use.

• Wide range of applications for high-quality products
• Do not contain nickel on surfaces in contact with drinking water
• 100% of the valves tested for tightness
• Reliable equipment for installations

Operating conditions:

• filled with 50% glycol solution
• at a pressure of 30 bar
• at a temperature of +140°C
• Environmentally friendly, fully recyclable
• Key data placed on the label (useful during installation)
• Self-locking nut preventing the loosening of the handle (not applicable for PHA-010)
• Product performance confirmed through testing in an independent, reliable, accredited laboratory
• Operational factors and applications supported by research leading to Technical Approval

Materials and maximum operating parameters:

• temperature: +150°C
• pressure: 3.0 MPa (30 bar)
• TUBE AND SCREW - brass CW617N with external gold plating (PHA-006 completely without gold plating)
• BALL - brass CW617N with chrome
• VALVES AND SEAL - brass CW614N
• SEALS FOR BALL AND VALVES - PTFE (Teflon)
• HANDLE - carbon steel with PVC coating in red or blue color or aluminum with paint in red or blue color
