Siemens Phase 2-Pole Earth Leakage Relay 10A 230V
Phase Relays

Siemens Phase 2-Pole Earth Leakage Relay 10A 230V

The Siemens 5SV1316-6KK10 residual current circuit breaker combines Type A residual current protection with a rated current of 10 A. Its 30 mA tripping sensitivity and 230 V operating voltage make it...

The Siemens 5SV1316-6KK10 residual current circuit breaker combines Type A residual current protection with a rated current of 10 A. Its 30 mA tripping sensitivity and 230 V operating voltage make it suitable for protection against electric shock and the effects of short circuits.

  • Type: Residual current circuit breaker
  • Number of poles: 2
  • Rated current: 10 A...
See Description & Specifications See Description & Specifications
158 25 €
Delivery Fri, 27 Nov - Tue, 01 Dec
3,50 € to a Skroutz Point or 4,50 € to an address
Do you want it with Free shipping?
Sent from Greece
From Getters 4.5 (117)
4.5 (117 reviews)
Greece
See Electrical Panel Supplies on the page of Getters

Shop selection criteria

Why do we recommend buying from this shop?

We don’t only look at the price. We weigh different factors to find an offer that combines a good price, fast delivery and a reliable purchase.

  • Product price

    We calculate the total price you will pay and any discounts available from the shop.

  • Shipping & delivery time

    We check how quickly the product can be shipped and when you will receive it, based on your address.

  • Shop reliability

    We look at how often shops complete their orders successfully and how consistently they serve their customers.

  • Official reseller

    Where available, we take into account whether the shop is an official reseller of the brand.
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund. Learn more

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Learn more about invoicing
Questions
Review the product
Product report

Description & Specifications

The Siemens 5SV1316-6KK10 residual current circuit breaker combines Type A residual current protection with a rated current of 10 A. Its 30 mA tripping sensitivity and 230 V operating voltage make it suitable for protection against electric shock and the effects of short circuits.

  • Type: Residual current circuit breaker
  • Number of poles: 2
  • Rated current: 10 A
  • Operating voltage: 230 V
  • Residual current protection type: Type A
  • Residual tripping current: 30 mA
  • Degree of protection: IP20
  • Mechanical service life: 10,000 switching cycles
  • Overvoltage category: III
  • Pollution degree: 2
  • Impulse current withstand: 1 kA
  • Supply frequency: 50 Hz
  • Switching capacity (EN 60898): 6 kA
  • Switching capacity (IEC 60947-2): 25 kA
  • Energy-limiting class: 3
  • Power loss in the hot state: 1.1 W
  • Maximum power loss: 2.2 W
  • Operating current at 40 °C: 9.4 A
  • Operating current at 70 °C: 7.4 A
  • Dimensions: 90 × 18 × 77 mm (height × width × depth)
  • Net weight: 117 g
  • Operating temperature: -25 °C to 45 °C
  • Storage temperature: -40 °C to 75 °C
  • Test cycles (IEC 60068-2-30): 28
  • Connectable conductors: Solid and stranded conductors, 0.75 mm² to 16 mm²; flexible conductors with ferrules up to 10 mm²
  • Standards: EN 60898 and IEC 60947-2
  • Series: SENTRON 5SV1

Manufacturer

Manufacturer Details

Warnings & Safety Information
Type
Earth Leakage
Number of Poles
2
Voltage
230 V
Nominal Voltage
10 A
Leakage Current
30 mA
with Energy Consumption Meter
No
with Timer
No
Type of Residual Current Relay
Type A

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
