Management Features

• Switch Type: Unmanaged

Connectivity

• Number of Basic Switching RJ-46 Ethernet Ports: 24
• Type of Basic Switching Ethernet Ports: RJ-45 Gigabit Ethernet (10/100/1000)

Networking

• Network Standard: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
• 10G Support: NO
• Auto MDI/MDI-X: NO

Data Transfer

• Address Table Size: 8000 entries
• Routing/Switching Capacity: 48 Gbit/s
• Forwarding Rate: 35.7 Mpps
• Jumbo Frames: 10000
• Packet Buffer Memory: 0.525 MB

Design

• Rack Mounting: NO
• Product Color: Black
• Communication LED Indicators: NO
• Wall Mounting: NO

Certifications

• ISV, LVD, BSMI, EMC Class A, CE, FCC, RCM, ICES-003, BSMI, RoHS, REACH

Performance

• Fanless: NO
• MTBF Rate: 366919h

Power Management

• Power Supply Included: NO
• AC Input Voltage: 100 - 240V
• AC Input Frequency: 50/60Hz
• Power Consumption (max): 13W
• Power over Ethernet (PoE) Technology: PoE Power Supply: NO

Environmental Conditions

• Operating Temperature Range: 0 - 40°C
• Heat Dissipation: 43.53 BTU/h

Weight and Dimensions

• Width: 267 mm
• Depth: 162 mm
• Height: 42 mm
• Weight: 1500 g

Package Contents

• Cables Included: AC
• Rack Mount Kit: NO
