The OPTI 9AH 12V AGM battery powers uninterruptible power supply (UPS) systems, automation systems, photovoltaic installations and voltage converters. It operates in standby charging systems and cyclic applications; at a depth of discharge of up to 50%, it provides approximately 600 operating cycles. Its service life at 25 °C is 5–8 years.
AGM technology uses glass-fibre separators to retain the electrolyte. It features an automatic sealing system and pressure-relief valves that safely release gas when internal pressure rises, such as in the event of overcharging. It requires no electrolyte top-up or replacement and can operate in any position. The casing is made of ABS, and the plates are made of copper.
- Technology: AGM
- Capacity: 9 Ah
- Voltage: 12 V
- Service life: 5–8 years at 25 °C
- Operating cycles: Approximately 600 at a depth of discharge of up to 50%
- Maximum charging current: 1.65 A at 25 °C
- Maximum discharge current: 55 A at 25 °C
- Casing material: ABS
- Plate material: Copper
- Terminals: Clamps
- Weight: 2.18 kg ± 5%
- Dimensions: 151 × 65 × 94 mm
- Applications: UPS systems, automation systems, photovoltaic installations, voltage converters, alarm and access control systems, cash registers, CCTV and telecommunications systems, emergency lighting, medical equipment, scooters, mopeds, toys, model aircraft, modelling and electric bicycles
- Capacity
- 9 Ah
- Voltage
- 12 V
- Loading Speed
- -
