Wall thickness electrode for welding structures of carbon steel with normal and high strength (Rp0.2 390 N/mm2) exposed to high static and dynamic loads. It is used in shipbuilding, mechanical engineering, and energy industries, as well as in metal constructions such as bridges and cranes. Capability to perform welds in vertical positions from top to bottom.
Welding current and polarity: direct current (+ on the electrode).
Typical alloy composition:
- C-0.07%
- Mn-0.8%
- Si-0.4%
Welding positions: PA, PB, PC, PD, PE, PF, PG.
Specifications
- Type
- Electrodes
- Weight
- 6 kg
- Pieces
- 1 pcs
Dimensions
- Diameter
- 3.2 mm
