The Apart Audio Revamp 2600 installation power amplifier drives two channels and delivers 300 W per channel at 8 Ω or 600 W per channel at 4 Ω. Its built-in digital signal processor lets you select an operating mode using a button on the rear panel, with presets for different applications, such as two-zone use or stereo operation.
Selected modes can combine a subwoofer on one channel with a transformer load on the other. The low-pass and high-pass filters support different configurations, while the low-pass filter can help maintain stability when using 100 V transformers at the output.
- Type: Installation power amplifier
- Channels: 2
- Power at 4 Ω: 600 W per channel
- Power at 8 Ω: 300 W per channel
- Class technology: H
- Digital signal processor: Built-in
- Operating mode presets: 9
- RCA inputs: 1
- XLR inputs: 1
- Width: 483 mm
- Height: 88 mm
- Depth: 332 mm
- Weight: 12.1 kg
Technical Specifications
- Amplifier Type
- Commercial Amplifier
- Type
- Power Amplifier
- Channels
- 2
- Power (8Ω)
- 300 watt / channel
- Power (4Ω)
- 600 watt / channel
- Class
- H
- Weight
- 12.1 kg
Additional Specifications
- Radio
- No
- Cooling system
- No
Connectivity
- RCA
- Yes
- XLR
- Yes
- Mini Jack (3.5mm)
- No
- Jack (6.3mm)
- No
- USB
- No
- Ethernet
- No
- Bluetooth
- No
- Mic In
- No
Dimensions
- Width
- 483 mm
- Height
- 88 mm
- Length
- 332 mm
