Product Series: PRO
Nominal Power (W): 12W
Supply Voltage (V): DC40V
Current (A): 300mA
Color Temperature (K): 2700K & 4300K & 6000K
Lumen Output (lm): 540lm
Lumen/ Watt: 45lm/Watt
Chip Size: SMD2835
Chip Brand: Epistar
Power Supply Brand: HAISRI
Power Supply Included: Yes
LED Type: SMD
Power Factor (PF): >0.50
Color Rendering Index (CRI Ra): >90
Lifetime (h): 30000h
Ingress Protection Rating (IP): IP20
Beam Angle: 36°
Ignition Time (sec): 0.5 sec
Energy Class: G
Switching Cycles (ON/ OFF): 15000
Operating Temperature °C: -20°C - +45°C
Mounting Height: 3 - 4mtr
Product Material: Aluminum & Plastic
Product Color: Black
Length: 222mm
Width: 25mm
Height: 27.5mm
Gross Product Weight (Kg): 0.176
Packaging (pcs): 150
Packaging: White with Sticker
Certificates: Yes
CE Mark: Yes
Connection Type: copper spot connector
Specifications
- Type
- Ceiling
- Placement
- Rail
- Power
- 12 W
- Light Colour
- Warm White
- Colour
- Black
Additional Specifications
- Magnetic
- Yes
- LED
- Yes
- Dimmable
- No
- Water Resistance Rating
- IP20
Dimensions
- Length
- 22.2 cm
- Height
- 2.5 cm
