The DIAMOND IW and DIAMOND OW speakers elevate the award-winning DIAMOND 12 series, creating an impressive range of architectural speakers that offer a truly immersive audio experience.
They create a lively sound that envelops you from all angles, experiencing every emotion with stunning detail. The recent in-wall and on-wall options are designed with an emphasis on the renowned principles of the DIAMOND 12 and are equipped with the innovative Klarity cone material, offering lightness and rigidity to the cones.
Features:
- Model DIAMOND OW-1
- General description: 2-way ‘on wall’ loudspeaker
- Enclosure type: closed-box
- Transducer complement: 2-way
- Bass driver: 6.5 (150mm) advanced PP Cone
- Treble driver: 1 (25mm) Textile Dome
- Sensitivity (2.83V@ 1m): 86dB
- Recommended amplifier power: 20-100W
- Peak power handling: 100W
- Peak SPL: 96dB
- Nominal impedance: 4Ω
- Minimum impedance: 3.9Ω
- Frequency response (+/-3dB): 80Hz~20kHz
- Bass extension (-6dB): 75Hz
- Crossover frequency: 2.6kHz
- Dimensions (mm) Height: 360mm
- Width: 200mm
- Depth: 141mm
- Net weight: 5.0kg/pcs
- Standard accessories: user manual, certificate
- Power
- 150 W
- Nominal Impendance
- 4 ohm
- Sensitivity
- 88 dB
- Driver Configuration
- 2 No of Drivers
- Placing
- Wall Mounted
- Bass Driver
- 6.5 "
- Dolby Atmos
- No
- Quantity
- Pair
- Colour
- White
- Width
- 20 cm
