Supplier Code: PRO
Supply Voltage (V): 220-240V
Maximum Output Power: 25-42V DC
Nominal Power (W): 7W
Current (A): 180mA
Operating Frequency (Hz): 50/60Hz
Type of Led: COB
Color Temperature (K): 3CCT(3000-4000-6500K)
Lumen Output (lm): 700lm
Lumen Output per Watt: 100lm/Watt
Lumen per Chip: 700lm/chip
Watts per Chip: 7W/Chip
Total Chips: 1pcs
Chip Size: COB
Chip Brand: Bridgelux
Power Supply Brand: Lifud
Power Supply Included: Yes
Power Factor (PF): >0.50
Color Rendering Index CRI (Ra): >80
Lifetime (h): 30000h
Ignition Time (sec): 0.5 sec
Switching Cycles (ON/OFF): 15000
Dimming: No
Energy Class: F
Ingress Protection Rating (IP): IP65
Impact Rating (IK): IK03
Operating Temperature °C: -10°C - +60°C
Beam Angle: 60°
Product Color: White
Product Material: Aluminum & Plastic
Net Weight of Product (kg): 0.400
Gross Weight of Product (kg): 0.450
Packaging (pcs): 120
Packaging: Color Box
Height: 60mm
Width: 88mm
Diameter: Φ88mm
Cutout Size: Φ75mm
Certificates: Yes
CE Marking: Yes
Mounting Height: 2 - 3mtr
Insulation Class: Class I
Connection Type: Cable
Object Grounding: No
- Product Number
- 145-68902
Specifications
- Material
- Metallic
- Operating Voltage
- 220-240 V
- Frame
- No
- Colour
- White
Dimensions
- Length
- 88 cm
- Width
- 88 cm
