Management Features

• Switch type: Unmanaged
• Quality of Service (QoS) support: NO

Connectivity

• Number of basic switching Ethernet ports: RJ-468
• Type of basic switching Ethernet ports: RJ-452.5G Ethernet (100/1000/2500)
• Number of SFP+ module slots: 1

Networking

• 10G support: NO

Data Transfer

• Address table size: 4000 entries
• Routing/switching capacity: 60 Gbit/s
• Forwarding rate: 44.6 Mpps
• Jumbo frames support: NO
• Jumbo frames: 12000
• Packet buffer memory: 1 MB

Design

• LED indicators: PoE, Power, Link
• Certifications: ISVCE, EAC, FCC, BSMI Class B

Performance

• MTBF rate: 858634h

Power Management

• Power source: DC
• Power supply included: NO
• AC input voltage: 100 - 240V
• AC input frequency: 50/60Hz
• Power consumption (max): 120W
• Power over Ethernet (PoE) technology: NO
• Number of Power over Ethernet ports: 4P PoE (PoE++): 8
• Total Power over Ethernet (PoE) budget: 100W

Environmental Conditions

• Operating temperature range: -20 - 40°C
• Storage temperature limits: -40 - 70°C
• Operating humidity range: 10 - 95%
• Non-operating humidity: 5 - 95%
• Heat dissipation: 91.1 BTU/h

Weight and Dimensions

• Width: 240mm
• Depth: 105mm
• Height: 27mm
• Weight: 715g

Data Packages

• Quick start guide: NO
