The Ruijie RG-ES08 switch is an unmanaged Layer 2 switch with 8 10/100 Mbps Ethernet ports and Plug & Play functionality. It supports Half-duplex, Full-duplex, Auto-negotiation and Auto MD/MDIX, and features a fanless design. It has a switching capacity of 1.6 Gbps and a packet forwarding rate of 1.1904 Mp/s.
- Type: Unmanaged Layer 2 switch
- Ethernet ports: 8 × 10/100 Mbps ports
- Operation: Plug & Play
- Port features: Half-duplex, Full-duplex, Auto-negotiation, Auto MD/MDIX
- Switching capacity: 1.6 Gbps
- Packet forwarding rate: 1.1904 Mp/s
- MAC address table: 1K entries
- Power consumption: 6.5 W
- Power supply: 5 V DC / 600 mA
- Cooling: Fanless
- Dimensions: 144 × 85 × 23 mm
- Operating temperature: 0 °C to 40 °C
- Operating humidity: 10% to 90% RH
- Enclosure material: Plastic
- Colour: Black
- Reset button: Yes
- Standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3x
- Compliance certification: CE
Network Specifications
- Type
- Unmanaged
- Layer
- L2
- PoE
- No
Technical Specifications
- Ethernet connections
- 8 Port
- Ethernet Speed
- 1000 Mbps
- Switching Speed
- 1.6 Gbps
- MAC Address Table
- 1000 entries
- Rack mounting
- No
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
