Measuring Range

• DC Voltage: 600 mV / 6 V / 60 V / 600 V / 1000 V ±(0.5%+2)
• AC Voltage: 6 V / 60 V / 600 V / 750 V ±(0.8%+3)
• DC Current: 60 uA / 600 uA / 6 mA / 60 mA / 600 mA / 20 A ±(0.8%+8)
• AC Current: 60 uA / 600 uA / 6 mA / 60 mA / 600 mA / 20 A ±(1%+12)
• Resistance: 600 Ohm / 6 kOhm / 60 kOhm / 600 kOhm / 6 MOhm / 60 MOhm ±(0.8% + 3)
• Capacitance: 6 nF / 60 nF / 600 nF / 6 µF / 60 µF / 600 µF / 6 mF / 60 mF / 100 mF ±(3%+10)
• ACV Frequency: 10 Hz~10 kHz ±(0.1%+5)
• Frequency: 9.999 Hz ~ 9.999 MHz (1%+5)
• Transistor HFE Measurement
• Diode Test
• Circuit Continuity Check

Additional Functions

• NCV (Non-Contact Voltage Detection)
• Manual Range Selection
• Live Wire Detection
• True RMS
• Burnt Fuse Alert
• Overload Alert: >= 20 A
• REL Function: Reset Reading
• Hold the Last Reading
• Backlight Display
• Max/Min Value Recording
• Sound/Light Signal: During Continuity and NCV Measurement
• Automatic Shut-Off
• Low Battery Indicator
• Maximum Reading: 6000

General Characteristics

• Power Supply: 2x AAA 1.5 V Batteries
• Screen Size: 56.5 x 36 mm
• Product Dimensions: 183x88x56 mm
• Product Weight: 346 g
• Operating Temperature: 0°C ~ 40°C
• Storage Temperature: -10°C ~ 50°C
• Relative Humidity: 0°C ~ 30°C
• Operating Altitude: 0 ~ 2000 m

Manufacturer: Uni-T
