Management Features

• Switch Type: Managed
• Layer Switching: L2
• Quality of Service (QoS) Support: NO
• Internet Management: NO
• Cloud-managed: NO
• MIB Support: NO

Connectivity

• Number of Basic Switching Ethernet Ports: RJ-46 24
• Type of Basic Switching Ethernet Ports: RJ-45 Gigabit Ethernet (10/100/1000)

Networking

• Network Standard: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.1p, IEEE 802.3u, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az
• 10G Support: NO
• Port Mirroring: NO
• Flow Control Support: NO
• Broadcast Storm Control: NO
• Spanning Tree Protocol: NO
• Ethernet LAN Data Rates: 100, 1000 Mbit/s
• VLAN Support: NO
• Virtual LAN Features: Port-based VLAN

Data Transfer

• Address Table Size: 8000 entries
• Routing/Switching Capacity: 48 Gbit/s
• Forwarding Rate: 35.7 Mpps
• Jumbo Frames Support: NO
• Jumbo Frames: 9000

Security

• DHCP Functions: DHCP relay, DHCP client
• IGMP Snooping: NO
• Security Algorithm Support: HTTPS, SSH-2, SSL/TLS, SHA-2
• SSH/SSL Support: NO
• Loop Protection: NO
• Password Protection: NO

Multicast Functions

• Multicast Support: NO

Protocols

• Management Protocols: SNMP v1, v2c, v3

Design

• Rack Mounting: NO
• Form Factor: 1U
• Product Color: Black
• Communication LED Indicators: NO
• Wall Mounting: NO

Performance

• Fanless: NO
• MTBF (PoE): 768989 h

Power Management

• Power Source: AC
• Power Supply Included: NO
• AC Input Voltage: 100 - 240V
• AC Input Frequency: 50 - 60Hz
• Power Consumption (max): 166.1W

Power over Ethernet (PoE) Technology

• PoE Power Supply: NO
• Number of Power over Ethernet (PoE) Ports: 12
• Total Power over Ethernet (PoE) Budget: 130W

Environmental Conditions

• Operating Temperature Range: 0 - 40°C
• Storage Temperature Limits: -40 - 70°C
• Operating Humidity Range: 10 - 95%
• Heat Dissipation: 566 BTU/h

Weight and Dimensions

• Width: 330 mm
• Depth: 230 mm
• Height: 44 mm
• Weight: 2480 g

Package Data

• Package Width: 389 mm
• Package Depth: 337 mm
• Package Height: 79 mm
• Package Weight: 3870 g
