Management Features

• Switch Type: Managed
• Layer Switching: L2
• Quality of Service (QoS) Support: NO
• Internet Management: NO
• Event Logging System: NO
• MIB Support: RFC 1213 MIB II, RFC 2819 RMON (group 1, 2, 3, 9), RFC 1215, RFC 1493

Connectivity

• Number of Basic Switching Ethernet Ports: RJ-46 24
• Type of Basic Switching Ethernet Ports: RJ-45 Gigabit Ethernet (10/100/1000)
• Number of SFP Module Slots: 2
• Power Supply Socket: AC-in jack

Networking

• Network Standard: IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
• 10G Support: NO
• Port Mirroring: NO
• Full Duplex: NO
• Flow Control Support: NO
• Link Aggregation: NO
• Spanning Tree Protocol: NO
• Ethernet LAN Data Rates: 10,100,1000 Mbit/s
• Automatic MAC Address Learning Support: NO
• VLAN Support: NO
• Virtual LAN Functions: Tagged VLAN, VLAN Identifier (VLAN ID), Voice VLAN

Data Transfer

• Address Table Size: 8000 entries
• Routing/Switching Capacity: 52 Gbit/s
• Forwarding Rate: 39 Mpps
• Store-and-Forward: NO
• Jumbo Frames Support: NO
• Jumbo Frames: 9000
• Packet Forwarding Rate (1 Gbps): 39 pps
• Packet Buffer Memory: 0.525 MB

Security

• DHCP Functions: DHCP client
• IGMP Snooping: NO
• Security Algorithm Support: 802.1x RADIUS
• MAC Address Filtering: NO
• Static Port Security: NO
• SSH/SSL Support: NO
• Password Protection: NO
• Authentication Type: RADIUS, TACACS+

Design

• Rack Mounting: NO
• Stackable: NO
• Form Factor: 1U
• Product Color: Black
• Reset Switch: NO
• Communication LED Indicators: NO
• ISVE Certifications: EMC
• CE, FCC, C-Tick, Class A
• CE, FCC, C-Tick, Class B
• BSMI CNS13438
• Safety: LVD EN60950-1
• BSMI CNS14336-1
• CB IEC60950-1
• RoHS compliant

Performance

• MTBF Rate: 432,673 h

Power Management

• Power Source: AC
• Power Supply Included: NO
• AC Input Voltage: 100 - 240 V
• AC Input Frequency: 50/60 Hz
• Power Consumption (max): 16 W
• Power over Ethernet (PoE) Technology: PoE Power Supply: NO

Environmental Conditions

• Operating Temperature Range: 0 - 50 °C
• Storage Temperature Limits: -40 - 70 °C
• Operating Humidity Range: 10 - 95%
• Non-operating Humidity: 10 - 95%
• Heat Dissipation: 55 BTU/h

Weight and Dimensions

• Width: 440 mm
• Depth: 131 mm
• Height: 44 mm
• Weight: 2090 g

Package Contents

• Cables Included: AC
• Packaging Type: Box
• Rack Mount Kit: NO
• Package Width: 561 mm
• Package Depth: 217 mm
• Package Height: 82 mm
• Package Weight: 2850 g
