Elmark El1bp339 Industrial Push Button Panel of Type 401349
Industrial Buttons

Elmark El1bp339 Industrial Push Button Panel of Type 401349

The Elmark EL1-BP339 control station features three spring-return push buttons with 1NO, 1NC and 1NO contacts. Two buttons are green and one is red, while the enclosure is black and grey.

Its IP65...

The Elmark EL1-BP339 control station features three spring-return push buttons with 1NO, 1NC and 1NO contacts. Two buttons are green and one is red, while the enclosure is black and grey.

Its IP65 protection rating and operating temperature range of -20 °C to +70 °C define its conditions of use. It can be mounted on a flat metal or plastic surface, with a...

See Description & Specifications See Description & Specifications
16 40 €
You earn a 10,00 € coupon
for your next purchase

Deals & Benefits

Κέρδισε κουπόνι 10€ με αγορά μέσω App!

Το θέλεις; Θα το ‘χεις! Κάνε μια παραγγελία άνω των 50€ από το Skroutz App μέσα στο ΣΟΥΚΟΥ και κέρδισε κουπόνι 10€ για την επόμενη παραγγελία σου άνω των 50€.

Η προσφορά ισχύει μέχρι την Κυριακή, 01/11, γι' αυτό βιάσου.

  • Απαραίτητη προϋπόθεση είναι η αγορά μέσω του Skroutz App.
  • Το κουπόνι 10€ ισχύει για μία (1) παραγγελία συνολικής αξίας προϊόντων άνω των 50€ με διεύθυνση αποστολής στην Κύπρο.
  • Το κουπόνι αποδίδεται αμέσως μετά την ολοκλήρωση της παραγγελίας με διάρκεια 5 ημέρες από την ημερομηνία απόδοσής του.

Terms & conditions apply
Delivery Thursday, 05 November
4,50 € shipping cost
Sent from Greece
From Lynk.gr 4.9 (10)
4.9 (10 reviews)
Greece
2 pieces
See Industrial Materials on the page of Lynk.gr
What if it breaks?

You're covered by the statutory 2-year warranty. Contact us and we'll handle the entire process with the store, ensuring your issue is resolved with prompt support through a repair, replacement, or refund.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Learn more about invoicing
Questions
Review the product
Product report

Description & Specifications

The Elmark EL1-BP339 control station features three spring-return push buttons with 1NO, 1NC and 1NO contacts. Two buttons are green and one is red, while the enclosure is black and grey.

Its IP65 protection rating and operating temperature range of -20 °C to +70 °C define its conditions of use. It can be mounted on a flat metal or plastic surface, with a panel cutout of Ø22.5 mm and a maximum panel thickness of 4 mm.

  • Type: Industrial control station with three push buttons
  • Mechanism: Spring return
  • Contacts: 1NO, 1NC, 1NO
  • Button colour: Green and red
  • Enclosure colour: Black and grey
  • Protection rating: IP65
  • Rated current at 400 V: 6 A
  • Rated current at 230 V AC: 6 A
  • Rated current at 230 V DC: 0.3 A
  • Insulation voltage: 660 V, 50/60 Hz
  • Impulse withstand voltage: 6000 V
  • Mechanical operating force when closing: 20 N
  • Mechanical operating force when opening: 8 N
  • Operating temperature: From -20 °C to +70 °C
  • Operating humidity: 35–85% RH
  • Panel cutout diameter: Ø22.5 mm
  • Maximum mounting surface thickness: 4 mm
  • Dimensions: 13.4 × 6.8 × 5 cm
