Wilo Initial Waste 14.9 Single-phase Pump Waste Water / Sewage 1.2hp 4168022
Submersible Water Pumps

Wilo Initial Waste 14.9 Single-phase Pump Waste Water / Sewage 1.2hp 4168022

Key features:

  • Maximum submersion depth: 5m
  • Cable length: 10m
  • Maximum temperature: +5°C to 35°C
  • Outlet: 1 ½
  • Power: 0.9 kW (1.2 Hp)
See full description

  • Horsepower

    Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).

  • Voltage

    Single-Phase

    Single-phase power supply refers to the provision of electrical energy from single-phase current (e.g., 230V AC), which is the most common type of supply for residential and small commercial applications.

  • Power

    It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.

  • Manometric Height

    10

    The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

    • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
    • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
  • See all

User Manual

190 00 €
Delivery Thu, 16 Jul - Mon, 20 Jul
7,50 € to a Skroutz Point or 8,50 € to an address
Do you want it with 2,50 € shipping to Skroutz Point?
Sent from Greece
From Lamas
Greece
2 pieces
See Water Pumps on the page of Lamas
What if it breaks?

You have at least a 2-year warranty. Contact us by phone and we will immediately take care of the repair, replacement or refund of your money, completely free of charge.

What if I change my mind?

No problem, as long as it's within 14 days. We'll come pick it up or you can choose the Skroutz Point that suits you, completely free for up to 2 times per year, and we'll refund your money. Get Skroutz Plus to enjoy unlimited free returns.

Product report

Description

Description

Submersible sewage pump from the manufacturer Wilo, used for pumping dirty water that may contain particles.

• It has a horsepower of 1.2hp and a power of 900W.

Features

The WILO Initial Waste 14.9 sewage pump is used for pumping predetermined sewage without feces and long-fiber components.

It has an ergonomic carrying handle, low weight, operational safety thanks to the integrated cooling jacket, mechanical seal with sealing chamber, and hermetically sealed motor.


Technical Specifications:

  • Power supply voltage: 230 V – 50 Hz
  • Power P1: 0.9 kW (1.2 Hp)
  • Protection rating: IP 68
  • Temperature: +5°C to 35°C
  • Max. Head: 10m
  • Max. Flow rate: 230 lt/min
  • Cable length: 10m
  • Free passage for solids: 20mm
  • Connection port: 1 ½’’
  • Built-in float switch
  • Weight: 6.4 kg
  • Dimensions: 21 × 23 × 40 cm

Does not include connection elbow.


Manufacturer

Manufacturer Details

Warnings & Safety Information
See full description

Specifications

Specifications

Product Guides

User Manual

Dimensions

Type
Waste Water / Sewage

Type

Waste Water / Sewage

Waste water / sewage pumps are used for pumping and transporting waste water, sewage, and other liquids containing solids or particles
Power Source
Electric

Power Source

Electric
The power supply refers to the pump's need for electrical energy from an external power source, such as single-phase or three-phase power.
Voltage
Single-Phase

Voltage

Single-Phase

Single-phase power supply refers to the provision of electrical energy from single-phase current (e.g., 230V AC), which is the most common type of supply for residential and small commercial applications.
Horsepower
1.2 hp

Horsepower

Horsepower indicates the kinetic power of the pump. Higher horsepower means more efficiency in water pumping, affecting the flow (l/h) and the head (m).
Power
900 W

Power

It is the energy consumed by the motor to pump water. The greater the power, the more effectively it can lift and move water, especially over long distances or heights.
Cable Length
10 m

Features

Electronic Level Sensor
No

Electronic Level Sensor

It automatically activates the pump without the classic hanging float switch. It is ideal for narrow spaces and pits, as there is no risk of it getting stuck anywhere and flooding the area.
with Cutter Impeller
No

with Cutter Impeller

Components that chop, "cut" solid materials, such as organic waste or other particles, before they pass into the pump. They are mainly used in sewage or dirty water pumps, preventing clogging or damage to the system.
Float switch
Yes

Float switch

It is a mechanism that automatically controls the operation of the pump. When the water level reaches a predetermined height, the float activates the pump.
Outlet Nozzle
1 1/2"

Outlet Nozzle

The outlet nozzle refers to the point or the external diameter of the pump from which the pumped water or liquid exits. It is an important feature for determining the connection of the pump with the piping system and affects the flow capacity of the liquid.
Vortex
No

Vortex

The vortex system in submersible water pumps uses vortex technology to create a rotating water current, which helps in the efficient transfer of water, even when it contains particles or solids.

Pumping Specifications

Maximum Head Height
10 m

Maximum Head Height: 10


The Maximum Head Height refers to the maximum height at which the pump can lift water against resistance (such as pipes or filters). As the head height increases, the pump's flow rate decreases.

  • The maximum head height is considered by manufacturers to be the point where the water will just barely reach.
  • The maximum performance is considered by manufacturers to be the water flow at 0-1 meter head height.
Maximum Output
13 m³/h

Maximum Output

The maximum output or flow of a submersible water pump, as defined by the manufacturers, is the maximum amount of water the pump can move under ideal conditions, usually with zero head (i.e., no lift resistance).
Pump Submersion Depth
5 m
Shallow Suction
No

Shallow Suction

This function allows the pump to suck water from an extremely low level (up to 1-3 mm), ideal for flooded floors and basements.

Materials & Construction

Set
No
Stainless
No

Important information

Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.

See all specifications

Reviews (2)

Reviews

5.0
2
5.0
Review this product
  1. 2
  2. 4 stars
    0
  3. 3 stars
    0
  4. 2 stars
    0
  5. 1 star
    0
Review this product
  • 5
    giorgosdarsaklis

    I have it for 5 years. Perfect performance for household use

    Translated from Greek ·
    Did you find this review helpful?
  • 5
    3 out of 3 members found this review helpful
    panosmtk1

    Verified purchase

    Very powerful and high-quality submarine.

    Translated from Greek ·
    Did you find this review helpful?
Questions (1)

Questions

15 users have this product and can help you

Ask for the product
0 Replies Reply to
See all questions (1)

Description & Specifications

Submersible sewage pump from the manufacturer Wilo, used for pumping dirty water that may contain particles.

• It has a horsepower of 1.2hp and a power of 900W.

Features

The WILO Initial Waste 14.9 sewage pump is used for pumping predetermined sewage without feces and long-fiber components.

It has an ergonomic carrying handle, low weight, operational safety thanks to the integrated cooling jacket, mechanical seal with sealing chamber, and hermetically sealed motor.


Technical Specifications:

  • Power supply voltage: 230 V – 50 Hz
  • Power P1: 0.9 kW (1.2 Hp)
  • Protection rating: IP 68
  • Temperature: +5°C to 35°C
  • Max. Head: 10m
  • Max. Flow rate: 230 lt/min
  • Cable length: 10m
  • Free passage for solids: 20mm
  • Connection port: 1 ½’’
  • Built-in float switch
  • Weight: 6.4 kg
  • Dimensions: 21 × 23 × 40 cm

Does not include connection elbow.
