Technology

• Analog circuits
• The discrete class AB amplifier 6000A delivers 50W per channel into eight Ohms, with a maximum current flow of 9 Amps under difficult loads.
• The amplifier's output uses CFB (Complementary Feedback) topology, ensuring excellent linearity and superb thermal stability.
• The significant 200VA toroidal transformer and 4x15000uF capacitance (60000uF total) help the amplifier maintain steady control of the music, allowing for an exceptional dynamic range.

Preamplifier

• The preamplifier section is kept as simple as possible to ensure signal purity, with input signals passing through a precise analog volume control.
• This control ranges from -80dB to +8dB in 2dB and 1dB steps.
• Much effort has been made in the physical design of the 6000A's circuit layout, protecting the sensitive preamplifier section from noise interference.

Technical Specifications 6000A

• Gain (max.): +8dB (Line), +55dB (Phono MM)
• Input Sensitivity: 720mV (Line, Volume = 0dB), 3.1mV (Phono MM, Volume = 0dB)
• Input Impedance: 10K (Line), 47K//100pF (Phono MM)
• Total Harmonic Distortion (THD):
• Frequency Response: 20Hz-20kHz (+/-0.1dB)
• Output Voltage: 2.3V max. (Volume = 0dB)
• Output Impedance: 120Ω
• Signal to Noise Ratio (S/N): > 110dB (Line, A-weighted), >76dB (Phono MM, A-weighted)
• DAC: D to A converter ES9018K2M
• Maximum Sampling Frequency: 192kHz
• Digital Filters: Fast roll-off, Slow roll-off, Minimum phase
• Amplifier Section Gain: +29dB
• Maximum Output Power: 2 X 50W (8Ω, THD), 2 X 75W (4Ω, THD)
• Maximum Output Current: 9A
• General:
• Standby Power Consumption:
• Dimensions (mm) (W x H x D): 445 x 80 x 330mm including feet, terminals, and controls
• Weight: 7.8kg (Net)
