The Eurolamp PLUS series square surface-mounted LED panel provides natural white light at 4000 K with a luminous flux of 1800 lm. It has an aluminium and plastic body, integrated SMD2835 LEDs and a driver.
- Installation: Surface-mounted
- Shape: Square
- Colour: White
- Material: Aluminium and plastic
- Power: 20 W
- LED type: SMD2835
- Total number of LEDs: 90
- Luminous flux: 1800 lm
- Efficiency: 90 lm/W
- Light colour: Natural white
- Colour temperature: 4000 K
- Colour rendering index: >80 Ra
- Beam angle: 120°
- Supply voltage: 85–265 V
- Current: 300 mA
- Operating frequency: 50/60 Hz
- Power factor: >0.90
- Dimming: Not supported
- Flicker-free: Yes
- Lifetime: 30000 h
- Start-up time: 0.5 s
- On/off switching cycles: 15000
- Ingress protection rating: IP44
- Impact protection rating: IK03
- Operating temperature: -10 °C to +60 °C
- Energy class: F
- Insulation class: II
- Connection: Cable
- Length: 22.5 cm
- Width: 22.5 cm
- Height: 3.2 cm
Specifications
- Placement
- Outdoor
- Shape
- Square
- Power
- 20 W
- Color Temperature
- 4000 K
- Light Colour
- Natural White
- Lumen
- 1800 lm
Dimensions
- Length
- 22.5 cm
- Length
- 22.5 cm
Important information
Specifications are collected from official manufacturer websites. Please verify the specifications before proceeding with your final purchase. If you notice any problem you can report it here.
